Legrand DAKER DK + 2 KVA

Legrand DAKER DK + 2 KVA

Charakteristika produktu

Online dvojitá konverzia

19" typ stojana

Účiník: 0,9

RS232 USB SNMP

Obojstranná obrazovka



Technical characteristics

Input voltage 176-280 V

Primary frequency 47.5-63 Hz

Number of phases primary 1

Output voltage 228-232 V

Secondary frequency 50-60 Hz

Output effective power 1800 W

Output apparent power 2000 VA

Number of phases secondary 1

SNMP Yes

Voltage type AC

Height 440 mm

Width 88 mm

Depth 600 mm

Weight 29.5 kg

Bridging time full load 0 min

Suitable for network-management Yes

USV- technology Online

Construction type 482.6 mm (19 inch) device

Max. voltage distortion output (linear load) 3 %

Output power factor 0.9

Overall efficiency 91 %

Efficiency in eco-mode 97 %

Potential free switch contact No

Auto shut down function No

Input connection C14

Number of output connections C13 6

Degree of protection (IP) IP21

Operating / setting temperature 0-40 °C

Storage temperature 0-50 °C

Supply current 13.6-13.6 A

Sound level 50 dB

Type of load Universal

With socket outlet Yes

Contains Batteries and/or Accumulator Yes
